musx::dom::others::StaffList Class Reference
Defines a staff list. See subclasses for how it is used. More...
#include <Others.h>
Inheritance diagram for musx::dom::others::StaffList:
Public Types | |
| enum class | FloatingValues : StaffCmper { TopStaff = -1 , BottomStaff = -2 } |
| Defines special assignment values used for floating staff assignments. More... | |
| Public Types inherited from musx::dom::Base | |
| enum class | ShareMode { All , Partial , None } |
| Describes how this instance is shared between part and score. More... | |
| using | SharedNodes = std::set< std::string > |
| The container type for shared nodes. | |
Public Member Functions | |
| OthersArray (const DocumentWeakPtr &document, Cmper partId, ShareMode shareMode, Cmper cmper) | |
| Constructor function. | |
| Public Member Functions inherited from musx::dom::OthersArray< StaffCmper > | |
| OthersArray (const DocumentWeakPtr &document, Cmper partId, ShareMode shareMode, Cmper cmper) | |
| Constructor function. | |
| void | integrityCheck (const std::shared_ptr< Base > &ptrToThis) override |
| Override of Base::integrityCheck. | |
| Public Member Functions inherited from musx::dom::OthersBase | |
| OthersBase (const OthersBase &)=default | |
| explicit default copy constructor | |
| OthersBase (OthersBase &&) noexcept=default | |
| explicit default move constructor | |
| Cmper | getCmper () const |
Gets the cmper key value. | |
| std::optional< Inci > | getInci () const |
Gets the optional array index (inci). | |
| Cmper | getRequestedPartId () const |
| If this instance was retrieved from an object pool, it contains the part ID that was used to retrieve it. If this value is different than getSourcePartId, then this instance is a copy of the pool instance. | |
| Public Member Functions inherited from musx::dom::Base | |
| virtual | ~Base () noexcept(false)=default |
| Virtual destructor for polymorphic behavior. | |
| DocumentPtr | getDocument () const |
| Gets a reference to the Document. | |
| Cmper | getSourcePartId () const |
| Gets the source partId for this instance. If an instance is fully shared with the score, the source is SCORE_PARTID. If an instance is partially shared or non shared, the source is the ID of the part that sourced it. | |
| ShareMode | getShareMode () const |
| Gets the sharing mode for this instance. | |
| const SharedNodes & | getUnlinkedNodes () const |
Gets the unlinked nodes for this instance. (Only populated for ShareMode::Partial) | |
| void | addUnlinkedNode (const std::string &nodeName) |
| Adds a shared node for this instance. | |
| virtual bool | requireAllFields () const |
| Specifies if the parser should alert (print or throw) when an unknown xml tag is found for this class. | |
Static Public Member Functions | |
| static const xml::XmlElementArray< StaffList > & | xmlMappingArray () |
| Required for musx::factory::FieldPopulator. | |
Additional Inherited Members | |
| Public Attributes inherited from musx::dom::OthersArray< StaffCmper > | |
| std::vector< StaffCmper > | values |
| Protected Member Functions inherited from musx::dom::OthersBase | |
| OthersBase (const DocumentWeakPtr &document, Cmper partId, ShareMode shareMode, Cmper cmper, std::optional< Inci > inci=std::nullopt) | |
| Constructs an OthersBase object. | |
| OthersBase & | operator= (const OthersBase &other) |
| Assignment operator delegates to base, preserving OthersBase state. | |
| OthersBase & | operator= (OthersBase &&other) noexcept |
| Assignment operator delegates to base, preserving OthersBase state. | |
| Protected Member Functions inherited from musx::dom::Base | |
| Base (const DocumentWeakPtr &document, Cmper partId, ShareMode shareMode) | |
| Constructs the base class. | |
| Base (const Base &)=default | |
| explicit default copy constructor | |
| Base (Base &&) noexcept=default | |
| explicit default move constructor | |
| Base & | operator= (const Base &) |
| no-op copy assignment operator allows subclasses to copy their values. | |
| Base & | operator= (Base &&) noexcept |
| no-op move assignment operator allows subclasses to move their values. | |
Detailed Description
Defines a staff list. See subclasses for how it is used.
Each value is a specific staff cmper or one of the StaffList::FloatingValues.
Member Enumeration Documentation
◆ FloatingValues
|
strong |
